AC Pracbox - AC Circuit Training Equipment

Training Kit for Teaching and Assessing AC Theory

AC theory is the subject apprentices find hardest, and the one where practical work gets dropped first when time runs short.

The AC Pracbox incorporates modern AC circuit training equipment that puts every component UEEEL0020 requires into one portable box, so the practical actually happens.

It keeps you compliant, cuts setup time, and keeps learners engaged.

Training Videos and Resources

We currently have more than 28 training videos to get you started, and we also provide virtual training to ensure you get the most out of the AC Pracbox.

Video Demonstration

Key features

Units of competency

This AC electrical training equipment is designed around these units of competency to make compliance easier

01 Innovative Features

With power resistors, capacitors, lamps and real inductors, plus a built-in single-phase supply, this AC circuit training kit displays True Power, Voltage, Current, Power Factor, Frequency and Energy on one screen, so the whole circuit can be discussed at once.

02 Ease of use

Every component was chosen from the performance requirements of UEEEL0020, so the box fits your curriculum rather than the other way around, making it easy to use and substantially reducing preparation time.

03 Units of Competency

Ideal for the following subjects:

UEEEL0020
UEENEEG102A (superseded)

Benefits

Compliance built In

Components were selected against every performance criterion, performance evidence requirement and range of conditions in UEEEL0020. Any practical you run on the Pracbox is compliant by design.

Theory that finally lands

AC theory is maths-heavy, and most apprentices learn by doing. The Pracbox lets them watch the concepts behave in a live circuit instead of on a whiteboard.

Set up in minutes, not hours

No hunting down resistors, inductors, meters and supplies before every class. Everything is in one place, laid out the same way every time, so every group gets the same demonstration.

Technical specifications

Australian made & trainer designed

The AC Pracbox is designed, manufactured and supported in Australia, and engineered by people who’ve taught and assessed the curriculum, backed by onsite and virtual training, a video library and the Infinispark Learning Platform.

Frequently Asked Questions

What is the AC Pracbox?

The AC Pracbox is portable AC circuit training equipment that brings every component required for UEEEL0020 into one unit. It includes power resistors, capacitors, lamps, real inductors and a built-in single-phase supply, so trainers can run hands-on AC practicals without setting up a full lab bench each time.

Does the AC Pracbox need an external power supply for assessments?

No. The AC Pracbox has a built-in single-phase supply, so you can run and assess AC practicals without an external source. The supply is limited to ELV (extra-low voltage) for safety, making it suitable for classroom and workshop use.

What makes the AC Pracbox different from general electrical training equipment?

Most electrical training equipment covers a wide range of topics but isn’t built specifically for AC theory, usually the subject apprentices find hardest and the first practical to get cut when time runs short. The AC Pracbox is built around AC circuits specifically, so it stays compact, quick to set up and matched to what the unit of competency requires.

Is the AC Pracbox suitable as classroom AC electrical training equipment for RTOs?

Yes. It’s designed around the UEEEL0020 units of competency, which makes compliance and mapping to training packages simple. Because it’s portable, it also works well for RTOs running practicals across different classrooms or off-site delivery, without needing a fixed lab setup.

What can students measure with this AC circuit training kit?

The built-in meter shows True Power, Voltage, Current, Power Factor, Frequency and Energy on one screen. This means the whole circuit can be discussed in one session, instead of students taking separate readings from several instruments.

Does the AC circuit training kit use real components or simulations?

Real components. The AC Pracbox uses actual power resistors, capacitors, lamps and inductors instead of simulated values, so students work with genuine circuit behaviour, including the small variations and real-world responses that simulations often leave out.
